6
Sample Wireless Network Connections (CH7486E model shown)
Your maximum wireless operation distance depends on the type of materials
through which the signal must pass and the location of your CH7486E and clients
(stations). CBN cannot guarantee wireless operation for all supported distances in
all environments.
Note: To get better wireless coverage, please put your
CH7486E wireless gateway VERTICALLY ONLY
Wired Ethernet LAN
You can easily connect any PC with an Ethernet cable to the CH7486E Ethernet
port. Because the CH7486E Ethernet port supports auto-MDIX, you can use a
straight- through or cross-over cable to connect a hub, switch, or computer. Use
category 5, or better, cabling for all Ethernet connections.
