Using The Diagrams to Understand the Display Functions
WARNING: NEVER USE AN OBJECT OTHER THAN YOUR FINGER TO PRESS THESE BUTTONS. DOING SO WILL RESULT IN
PERMANENT DAMAGE TO THE CONTROLLER OVERLAY.
Below is a sample display window as they’re shown in the following section. Use the diagram to become familiar
with the way this section is organized, and how the information is presented in reference to each display
window and it’s functions. (NOTE: Tolerance on Liquid Level Display is +/- 1” (2.54cm) and the tolerance on the
temperature display is +/- 1°C)
SAMPLE DISPLAY WINDOW
X’s ARE USED IN PLACE OF NUMBERS IN THE DISPLAY WINDOW, SINCE THE ACTUAL NUMBERS WILL VARY.
THIS NUMBER TO THE LEFT OF
EACH WINDOW IS A GENERAL
IDENTIFICATION NUMBER
USED TO ORGANIZE THE
DISPLAYS FOR THIS MANUAL.
THIS NUMBER WILL NOT
APPEAR ANYWHERE ON THE
CONTROLLER OR THE ACTUAL
DISPLAY WINDOWS
THE TEXT TO
THE RIGHT OF THE DISPLAY
EXPLAINS THE SPECIFICS
OF THE DISPLAY MESSAGE AND
WHY IT IS OCCURRING
This is the standard display
which will appear during normal
operation under most circumstances.
Press this button to
advance to display #99
(see page 15) and print
report (see page 19)
Press this button to
begin a manual ll
#1
THE TEXT BELOW THE BUTTONS EXPLAINS
THE FUNCTION OF EACH OF THE BUTTONS.
ALSO TELLS WHICH DISPLAY THE BUTTON WILL
ADVANCE TO, AND THE PAGE NUMBER WHERE IT
CAN BE FOUND IN THE INSTRUCTION MANUAL
This is the standard display
which will appear during
normal operation under most
circumstances.
NOTE: Use Up/Down arrows to toggle
display between Temp. A and Temp. B
#1
#2
This display will appear during normal
operation when either a manual or
automatic ll is occurring.
