TABLE OF CONTENTS
Q&A Page 1
Safety 2-3
V Series and S Series Vessel Descriptions 4
Initial Set-Up 5
Operation 5
Front Panel Controls (ALL) 6
2301 Back Panel 7
Series 5000 Back Panel 8
V Series Manual Fill Instructions 9
Feature Details 10-11
Remote Alarm Wiring 12
Storage Unit Parameters 12
LCD Display Functions 13
Standard Operating Mode 14
Programming Mode 16
Verication & Calibration
High & Low Alarm Set Point Verication 26
Temperature Display Verication 26
2301 Temperature Calibration 27
V Series Level Display Verication & Calibration 28
Trouble Shooting 29-33
Plumbing Wiring Diagram Part ID 34
Plumbing Assembly Diagram 35
2301 Controller Wiring Diagram 36
2301 Controller Diagram Part ID 37
5000 2301 Controller Diagram Part ID 38
Series 2301 Controller Back Panel Part ID 39
Series 5000 2301 Controller Back Panel Part ID 40
90 Series Tank Diagram Part ID 41
S-1500 Series Tank Diagram Part ID 42
V-1500 Tank Diagram Part ID 43
3000 Tank Diagram Part ID 44
5000 & 5000EH Tank Diagram Part ID 45
Console and Rear Service Cover Assembly 46
Probe Assembly Diagram Part ID 47
Cleaning and Maintenance 48
EMC Test Report 49
Notes 50
