. Day / Night Mode .
The PBX can be configured in 2 sets of programming. One for the day mode and one for the night mode.
To change the system to Day Mode, Dial # 20
To change the system to Night Mode, Dial # 21
Default: Day Mode.
Note: The command can be given from the programming extensions only i.e., 601, 602, 603 and 604.
. Denied Table – A .
Numbers to be disallowed to extensions whose L = 4, are to be defined in this table. For value of L refer “Junction Dialing
Controls”.
This table has 16 Locations.
Procedure: Dial #0000 + 41 QQ ABCD#
Where QQ= 01 to 16 (16 Locations of the Table)
ABCD= The starting 4 digits of the Tel numbers to be denied to extension.
For less than 4 digits, dial # at the end of digits.
To clear this Table: Dial #0000 + 41 #
To clear a particular location of this table: Dial #0000 + 41 QQ #
. Denied Table – B .
Numbers to be disallowed to extensions whose L = 5, are to be defined in this table. For value of L refer “Junction Dialing
Controls”.
This table has 16 Locations.
Procedure: Dial #0000 + 42 QQ ABCD#
Where QQ= 01 to 16 (16 Locations of the Table)
ABCD= The starting 4 digits of the Tel numbers to be denied to extension.
For less than 4 digits, dial # at the end of digits.
To clear this Table: Dial #0000 + 42 #
To clear a particular location of this table: Dial #0000 + 42 QQ #
. Do Not Disturb (DND) .
In DND mode, no one can call the DND extension
PROCEDURE: Dial # 83
To cancel DND, simply lift Handset.
. Door Phone .
Upto 2 Door Phones can be connected to the PBX.
Open the back cover of the Door Phone and connect 2 wires on the Terminal block.
These 2 wires are to be connected to any of the Extension port (from 601 to 616) of the PBX.
To define the Extension as the first Door Phone extension, program as below:
Dial #0000 + 80 N #
Where, N= 01 – 16 (Representing the Extension numbers from 601 to 616)
To define the Extension as the second Door Phone extension, program as below:
Dial #0000 + 81 N #
Where, N= 01 – 16 (Representing the Extension numbers from 601 to 616)
To make the first Door Phone extension as a normal Extension, program as below:
Dial #0000 + 8000 #
To make the second Door Phone extension as a normal Extension, program as below:
Dial #0000 + 8100 #
Door Phone ring assignment
Dial #0000 + 82 N # - To assign extensions to ring when Door Phone calls.
Where, N= 03 – 16 (Representing the Extension numbers from 603 to 616)
Repeat the program for upto 6 Extensions maximum.
Dial #0000 + 82 # - To clear all programmed extensions for Door Phone calls.
Default: Extension 601 and 602 are assigned Door Phone Calls and these extensions cannot be removed from Door
Phone Calls ringing.
Note: Maximum 8 Extensions can be defined for Door Phone call. Out of these 8, two extensions 601 and 602 are fixed.
: Extensions cannot initiate call to talk to Door Phone.
: 416S doesn’t have Door Phone option as given above. However, “Door Phone- General Type” can be used with it.
. Door Lock .
The PBX has Stereo Jack marked as “Door”. Although Stereo Pin has 3 connections but only 2 connections are used. The
Shield point and any of the other 2 points.
These 2 points of the Jack basically work as a switch to complete the circuit for supply to Door Lock.
To set the Time duration for which the Door Lock circuit is to be operated, program as below:
