Oven Doors
Removing the Oven Doors
The oven doors can easily be removed as follows:
– Open the door to the full extent (fig. 12a).
– Open the lever A completely on the left and right hinges (fig.
12b).
– Hold the door as shown in fig. 12.
– Gently close the door (fig. 12c) until left and right hinge levers
A are hooked to part B of the door (fig. 12b).
– Withdraw the hinge hooks from their location following arrow
C (fig. 12d).
– Rest the door on a soft surface.
– To replace the door, repeat the above steps in reverse order.
B
A
C
Fig. 12 Fig. 12d
Fig. 12c
Fig. 12b
Fig. 12a
A
B
C
