Installation
Assembling the extractor ready for mounting:
4. Assemble the upper (B) and lower (C) support sections at the desired
height (as calculated in step 3) using the supplied screws (G) as shown in
fig 13.
5. When the support sections have been securely fastened together, fit the
upper(B) and lower(A) chimney sections over the supports, as shown in
fig 14.
Fig. 13
Fig. 14
