23
If fitting the hob into a 28-40mm worktop:
The four fixing clips supplied should be used. If fitting the hob into a
thin worktop (i.e. 28mm), then we recommend using four 15x15x50mm
wooden batons in addition to the brackets (as per figs. 9 and 10).
1. worktop
2. screw
4. hob
5. seal
1. worktop
2. screw
4. hob
5. seal
6. wooden block
5 4
321
51
15
6
5 4
321
042
753
094
nim
06
nim
05
042
091
753
094
nim
06
nim
05
091
05
Fig.9
Fig.10
Fig.11
Fig.12
2. Make sure that the worktop is clean and dust free and insert the
hob into the cut-out opening. Press the hob firmly into place so
that the seal connects with the worktop (Fig. 7).
Position the fixing brackets perpendicularly to the hob’s edge and
tighten firmly. Do not use power tools to do this.
