Using your hob
Zones:
1. Front left
Power Booster induction
cooking zone
2. Back left
Booster induction cooking zone
3. Back right
Booster induction cooking zone
4. Front right
Booster induction cooking zone
Control Panel
41110 8
12
13 14 15
3
2
5
6
7
1
9
1. Sensor on/o board with LED
2. Minus power setting sensor
3. Plus power setpoint sensor
4. Cooking zone indicator
5. Clock sensor
6. Clock sensor +
7. Clock sensor -
8. Clock indicator
9. Sensor key
10. Sensor pause
11. Sensor power amplifier
12. Temperature maintenance
program 40
o
13. Temperature maintenance
program 70
o
14. Temperature maintenance
program 90
o
