CDA sk400 - Page 23

23
Changing the bulb - Lateral lights (Figs 10 & 11)
•Removeallshelvesandthegrillpanfromtheoven.
•Gentlyunclipthesiderackfromitslowerlocatingstudandunhook
its top to remove it.
Note: No tools are required and the stud should not be removed.
•Carefullydetachtheglasscoverfromthelampholder,bysliding
it upward then easing the bottom
outward.
•Carefullyremovetheoldbulband
insert a new bulb, suitable for high
temperatures (300ºC) having the
following specifications: 230-240V,
50Hz, 25W, G9 fitting.
•Insertthenewbulbtakingcarenot
to touch the glass with your hands as
contamination from your fingers can
cause premature failure. Always use a
clean cloth or gloves.
•Reattachtheglasscover,pressingit
firmly into position.
•Replacethesiderackbylocatingthe
two hooks at the top and clipping it
back into position on its lower fixing
stud.
•Replacetheovenshelvesandgrill
pan as necessary.
Fig. 11
Fig. 10
