23
This appliance is supplied with a 3 core mains cable; the wires are in
accordance with the following code:
Green and Yellow = Earth
Blue = Neutral
Brown = Live
Please note:
• The mains cable must only
be replaced by a qualified
electrician or service engineer
and must be of equivalent
or better rating (i.e. 1.5mm
2
,
HO5V2V2-F).
• The current rating of the fuse or circuit breaker protecting this
appliance should be marked on the socket outlet (13A).
• Assembly and electrical connection should be carried out by
specialised personnel.
• When installing this product we recommend you seek the help of
another individual. The mains isolation switch must be accessible
after installation.
Mains electrical voltage: 230 – 240Vac, 50Hz
Total rated electrical consumption: 1.2 - 1.3 kW
$/5",%0/,%37)4#(%$
FUSE SPUR OUTLET
USE A 3 AMP FUSE
USE A 13 AMP FUSE
