CDVI PROFIL100EC - PROGRAMMING FLOWCHART - PART 1; Illumination Duration (A0); Time Relay Outputs (A1, A2); Code Length and Master Code (A4, A5)

EN
PROFIL100EC
Keypad PROFIL100EC
8 cdvigroup.com
Enter Master code
twice
Illumination
duration
10-99 sec
00 =
permanent
10 = default
Time relay 1
01-99 sec.
00 = toggled
01 = default
Time relay 2
01-99 sec.
00 = toggled
01 = default
Code length
4’ 5’or 6’ digits
5 = default
Master code
Change
master code
12345 =
default
2 x beeps
1 x beep = OK
4 beeps = ERROR
A0
1 x beep = OK
4 beeps = ERROR
A1
1 x beep = OK
4 beeps = ERROR
A2
1 x beep = OK
4 beeps = ERROR
A4
1 x beep = OK
4 beeps = ERROR
A5
1 x beep = OK
1 x beep = OK
1 x beep = OK
1 x beep = OK
1 x beep = OK
