CDVI V3S User Manual

Electromagnetic locks surface mount series
INSTALLATION MANUEL
2
cdvi.com
cdvigroup.com
1] PRODUCT PRESENTATION
The new range
of electromagnetic locks
with signalling on the
300, 400 and 500 kg
versions, suitable for the
new regulations covering
assistance to persons
with reduced mobility.
NFS 61-937.
Surface mounting.
High corrosion resistance.
Safety rope.
Delivered with armature.
No mechanical wear.
Ease of installation.
Recommended for interior use.
Positive safety (frees access immediately
in the event of a power cut).
Holding force: 300/400/500kg.
Visual and audible signalling
(depending on the version, see table).
No residual magnetism.
Built-in electronic protection
to eliminate back EMF.
Electromagnetic lock dimensions (l x w x d):
- 300kg range = 248 x 45 x 26mm,
- 400kg range = 255 x 50 x 27mm,
- 500kg range = 266 x 66 x 40mm.
Armature dimensions (l x w x d):
- 300kg range = 185 x 38 x 11mm,
- 400kg range = 185 x 45 x 12mm,
- 500kg range = 185 x 60 x 12mm.
Silent operation.
Option: Electromagnetic lock accessories.
Power supply: 12/24V dc.
Power absorption:
- 12 V DC = 550mA,
- 24 V DC = 275mA.
Relay/Signal:
CDVI CDVI UK
V3SR S300M
V4SR S400M
V5SR S500M
Relay/Signal + buzzer:
- V3SRB
- V4SRB
- V5SRB
ARD2/12 BS602
Recommended
power supplies
Reference
Holding
force
Signalling
CDVI CDVI UK Illuminated Audible
V3S S300 300kg Blue -
V4S S400 400kg Blue -
V5S S500 500kg Blue -
V3SR S300M 300kg
Red - Green
-
V4SR S400M 400kg Red - Green -
V5SR S500M 500kg Red - Green -
V3SRB 300kg Blue - Green Yes
V4SRB 400kg Blue - Green Yes
V5SRB 500kg Blue - Green Yes
BUZZER
COLOUR CODES:
BLUE ACTIVE VOLTAGE
RED LOCKED
GREEN OPEN
BLUE LOCKED
GREEN OPEN + BUZZER
EC certifi cation
WEEE & RoHS
IP42
