CDVI V3S User Manual

Electromagnetic locks surface mount series
INSTALLATION MANUEL
5
cdvi.com
cdvigroup.com
Electromagnetic lock
Armature
Adjustable
Inward opening door (Pull door)
(installed with “Z” and “L” brackets)
Z shaped bracket :
Z3/Z4/Z5
L shaped bracket :
- L3L4 (300 - 400 Kg),
- L5 (500kg).
L shaped bracket
Z shaped
bracket
Installation on an inward opening door (Pull door)
Mounting plate
Electromagnetic lock
Surface
mounting lock
Fixing screw
Armature
M8
screw
Cap nut
Guide piece
Rubber washer
Rubber washer
Roll pin
Roll pin
Steel washer
Steel washer
Armature
M8 screw
Rubber washer
Mounting plate
Door frame
Door frame
Outwards opening door (push door).
Electromagnetic
lock
Armature
Cap nut
Guide piece
M8 screw
OUTSIDE
OUTSIDE
INSIDE
INSIDE
Door
Door
Installation on an outward opening door (Push door)
6] INSTALLATION ON THE DOOR
