CEA MATRIX 3000 AC/DC R - Interfacing Accessories (Optional)

5
Interfacing accessories (optional)
“RoboMAT 1” analogue / digital robot interface
Fitted on the back of the MATRIX 3000 AC/DC R welding machine
(Pos. 1, Fig. B).
“RoboMAT 1” analogue / digital robot interface
connection cable - Cutting robot or for automatic
equipment
Connect the cable to the analogue / digital interface as shown in
figure (Pos. 2, Fig. B).
To connect the other end of this cable see the diagram in the man-
ualfor the “RoboMAT 1” analogue / digital robot interface.
IMPORTANT: Do not keep the “RoboMAT 1” analogue / digital ro-
bot interface connected to the generator, unless it is also powered
by the automatic system.
1
2
FIG. B
6
7
8
1
2
5
5
3
4
4
1
2
MATRIX 3000 AC/DC - AC/DC R
MATRIX 2200 AC/DC
6
7
8
3
FIG. A
