BONGO D40 XL CONNECTED
65
ENGLISH
4. PRODUCT ASSEMBLY
Unfolding
1. Detach the retaining bracket and pull the stem upwards.
2. Raise the stem and move the folding lever to the closed position to lock the stem in place.
3. Adjust the brakes with the Allen key.
Folding Fig. 25
1. Press the blue plate to release the folding lever.
2. Move the folding lever.
3. Turn the folding lever downwards and then the stem.
4. Align the locking hook with the hole in the retaining bracket.
Assembling the handlebar
1. Connect the male connection cable of the handlebar to the female cable of the stem. Make
sure the male and female ports are correctly aligned.
2. Insert the handlebar into the top of the stem and screw it in place.
Caution: Be careful not to damage the cable during the process.
Checking the screws
Some of the screws of the electric scooter may loosen during delivery. Please check all screws
and tighten them before turning on the electric scooter.
Charging the electric scooter
1. The scooter is fully charged when the LED light on the charger changes from red (charging)
to green (charging complete).
2. The charging port is located on the bottom left-side area of the scooter, protected by a
rubber cap to prevent dirt or water from entering.
3. Remove the rubber cap.
4. Connect the charger to the charging port.
5. When charging is complete, ret the rubber cap.
5. OPERATION
5.1. Switch-on and driving. Fig. 23
1. Hold down the power button for 2 seconds.
2. Step on the deck with one foot and use the other one to propel yourself forward.
3. Place both feet on the deck.
4. Press the accelerator with your right hand. The electric motor will deliver power when the
speed of the scooter is equal to or greater than 3 km/h.
5. Press the accelerator to increase the speed.
