ENGLISH
22
Main body and sensors
1. Back home button
2. Power button/Auto cleaning mode
3. Wi-Fi network con guration (Back home
and power button)
4. Cover release tab
5. Laser radar
6. Top cover
7. Power and back home buttons
8. Infrared receiver sensor
9. Anti-collision sensor
10. Omnidirectional wheel
11. Charging terminals
12. Battery
13. Side brush
14. Free-fall sensor
15. Main brush cover
16. Main brush
17. Left side wheel
18. Right side wheel
Wet & dry tank Available optional accessories:
1. Water inlet
2. Wet & dry tank
3. Tank clip
4. High-ef ciency lter
Charging base Mop
1. Signal transmission area
2. Charging terminal
3. Charge indicator
4. Charging terminal
5. Cord storage
1. Mop
2. Mop bracket
3. Velcro
4. Clip
2
3
5
4
1
1
2
3
4
1
4
2
3
1. Special silicone brush for pet hair.
2. Dust tank.
3. Remote control.
