ENGLISH
1. PARTS AND COMPONENTS
Fig. 1
1. On/o button
2. Back home button
3. Laser
4. Reset button
5. Optical sensor
6. IR sensor
7. Charging terminals
8. Free-fall sensors
9. Internal battery
10. Omnidirectional wheel
11. Driving wheels
12. Charging terminals
13. Main brush
Robot accessories:
14. Charging base
15. Side brush x 4
16. Mop x 2
17. Mop bracket
18. Mixed tank compatible with the autoclean base
19. Main brush frame
20. Charger
21. Autocleaning brush
22. High-eciency lter x 2
23. Jalisco brush
Charging base
Fig. 2.
1. Operation indicator
2. Signal transmission area
3. Charging terminals
4. Rear cover
5. Charging connector
Wet & dry tank
Fig. 3.
1. High-eciency lter
2. Charging terminals
