What if . . .?
CF•13.3 B / CF•13.3 B-L
ENGLISH
Problems with cutting
ATTENTION
Care and maintenance work as well as upkeep/repair of the joint cutter and the diamond saw blades must be done by
CEDIMA® and/or personnel approved by CEDIMA®!
The problems and their possible causes are mostly a result of natural wear and tear and in the incorrect handling of the
joint cutter or the diamond saw blade)!
Therefore you should read this operating manual thoroughly!
Problem Possible cause Remedy
Eccentric wear on the
diamond segments
Support of the saw blade is worn out (cutting
shaft, saw blade hole)
Saw blade ange dirty and/or defective
Cutting shaft has shrunk
Too much bearing play of the cutting shaft
Turn the saw blade location bore and let a ring be t in
Clean, check saw blade anges, replace if necessary
Check saw blade attachment of the cutting shaft, replace cutting
shaft if necessary
Replace cutting shaft
Replace bearing or cutting shaft
Little or no ow of cooling
water
Water supply not set to the optimum
Water hoses jammed, defective, o, bent
Shuto valve clogged, defective, not open
Adjust compressed water supply
Clean, check, connect or replace water hoses
Clean, check, open or replace shuto valve
9.0 Return of machines / disposal
CEDIMA
®
commits to take the joint cutter CF•13.3B / CF•13.3B-L back for disposal.
The joint cutter can be delivered free of charge at CEDIMA® or at a point of acceptance appointed by CEDIMA®.
