Maintenance and care -
Joint Cutter CF-22 E.800
Before
each
start-up
After
end of
work
every
work day
First time
after 10h
Weekly Monthly
after
3 - 6
months
Annu-
ally
In case of
faults
In case of
damage
Entire machine
3 1 3 3
Electrical system (switches, ...)
7 7 7 7 7 3 4
Tool receptacle (anges and saw
blade receptacle)
1. 3 1. 2 3, 5 4
Tool
(diamond saw blade)
3. 6 1 4
Operating elements
(handles, crank handle, ...)
3 1 4
Water system (hoses,
shut-o valve, ...)
3 1 1. 3. 5 4**
V-belts
3 3. 5 3 4 3 4*
Threaded spindle
1. 3. 2 3. 4* 4**
Engine housing
3 1
Engine
3. 7 1. 3. 4*. 5 4*
Parking brake
3 3, 5 4*
Reachable connecting elements
(nut, screws, ...)
5
Wheels
3 1 1. 3. 4*. 5 4**
h = operating hours *) Depending on load, conditions, condition **) Depending on severity (extent) of damage
1 clean
2 grease, lubricate, oil, corrosion protection
3 check (visual, function)
4 replace, exchange
5 Retighten, adjust,
replace wear parts
6 Replace if required
7 Statutory safety test (see section 5.6)
You will nd the description of the maintenance work in the following and corresponding chapters of this operating manual!
The table can be updated by CEDIMA® at any time (e.g. to comply with technical necessities and developments)! Please inquire about it with CEDIMA®!
5.5 Maintenance intervals for the CEDIMA® joint cutter CF-22 E.800
