NewTom GO 2D/3D - TECHNICAL MANUAL
COVER, HANDLES, MIRROR REMOVAL
2. COVER, HANDLES, MIRROR REMOVAL
2.1 MONOBLOC COVER
Remove the highlighted screws and pull the (interlo-
cking) cover.
2.2 PANEL COVER
Remove the highlighted screws and pull the (interlo-
cking) rear cover.
Loosen the four highlighted screws to remove the
front cover.
