POWERED SUBWOOFER
PARTS LIST
PRE AMP & POWER AMP ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1 1402-3070-0 X'FORMER MTG. BKT T1
1 1403-6370-0 REAR PANEL FC310C (CELESTION) T1
1 1725-327A-0000 INSULATION PCB-3 PANEL
1 1806-2413-0 TT-00017 115V/230V TOROIDAL TRANSFOMER T1
3 2436-6501-1 VOL/FREQ KNOB VR FREQ PHAS
6 2600-3005-0800 METAL WASHER M3X0.5X8MM ZNC PWRM-PCB,Q16,Q17
1 2606-3005-0643 INT TEETH WASHER M3X0.5X6.4MM BZ PANEL
1 2606-4008-0853 INT TOOTH WASHER M4X0.8X8.5MM BZ EARTH
12 2607-3009-0550 SPRING WASHER M3X0.9X5.5MM ZNC IEC1,PWRM-PCB, Q16,
Q17,VOLT-PCB
5 2607-4010-0704 SPRING WASHER M4X1X7MM NI EARTH,T1
2 2640-3022-0540 M3 NUT IEC1
5 2640-4030-0704 NUT HEX M4 EARTH,T1
2 2842-6213-0 METAL WASHER (M6X1.0X13MM) T1
8 2904-3006-3000 SCREW M3X6 BINDING (BLK) PANEL,VOLT-PCB
2 2904-3010-3000 SCREW M3X10 (BLK) IEC1
5 2904-4010-3000 SCREW M4X10 (BLK) PANEL,T1
7 2954-3008-3000 T3X8MM SELF TAPPING H.S,RCA1,SPK
4 2954-3010-3000 B-TITE 3X10MM (BLK.ZN) H.S
2 2954-3012-3000 3X12MM B-TITE (BLK.ZN) Q16,Q17
2 3100-3171-0 MICA SHEET A (24X20) Q16,Q17
4 4135-0271-0 BRASS TUBE 6XM3X12MM PANEL
1 4153-1250-0 2209 SW COVER 1-41-112 SW1
1 4153-3800-0 POWER INLET SOCKET SC9F-21 IEC1
2 5120-0078-0 FUSE T2.5A 250V 5X20MM UR & SEMKO F1
1 5200-4725-0 SWITCH ROCKER 2P1T SW3
1 5400-3311-0 HEAT SINK FC310C Q16,Q17
5 6360-0011-0 PLASTIC CABLE TIE 97MM T1/IEC
2 7010-2217-0 250 T'NAL ASSY L=120MM RED IEC1
2 7010-2218-0 250 T'NAL ASSY L=100MM RED SW3
2 7010-2219-0 250 TNAL ASSY L=100MM BROWN SW3
1 7010-2223-0 RING T'NAL ASSY L=80MM G/Y EARTH
1 7010-2236-0 250 TNA'L ASSY L=130MM BROWN IEC1
