POWERED SUBWOOFER
PARTS LIST
PRE AMP SECTION
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
1 150F-101K-5-IEA CC 50V 100PF 10% RL 5X3 C29
1 150F-104M-N-FD CC 50V 0.1µF 20% RLF C27
2 150F-271K-5-IEA CC 50V 270PF 10% RL 5x3 C3,11
4 150F-334M-N-JJA CC 50V 0.33µF 20% RLF MO C4,5,12,13
7 153H-104K-5-QUA CM 100V 0.1µF 10% RL 9X11 CENTRALAB C7,15,17,18,19,20,22,
2 153H-333K-5-MRA CM 100V 0.033µF 10% RL 7X9.5 C16,808
2 153H-683K-5-PSA CM 100V 0.068µF 10% RL 8.5X10 C62,63
1 157C-477M-5-OU CE 10V 470µF 20% RL 8X11 C24
2 157D-107M-5-KW CE 16V 100µF 20% RL 6x12 C21,25
1 157D-476M-5-IU CE 16V 47µF 20% RL 5x11 C26
2 157E-106M-5-IU CE 25V 10µF 20% RL 5x11 C23,30
5 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11 C1,2,9,10,28
1 2101-9790-0 4RCA JACK HSP-204V-03 GP RCA1
1 2113-1719-0 8P SPEAKER TERMINAL BOARD PT-801-01 SPK1
1 2600-3005-0800 METAL WASHER M3X0.5X8MM ZNC D11
8 3131-6140-0 IC BA4560 ROHM U1,2,3,4,5,6,7,8
1 3700-4536-RG L-115W EGW/209EGW RED/GR ELE-LED02 LED1
4 4701-102J-2 RCF 1/8W 1K 5% AT R11,34,71,73
23 4701-103J-2 RCF 1/8W 10K 5% AT R3, 6, 10, 15, 16, 18, 19, 21, 23,
26, 29, 33, 38, 39, 41, 42, 44, 46,
60, 61, 62, 70, 76, 79
4 4701-123J-2 RCF 1/8W 12K 5% AT R5,20,28,43
1 4701-125J-C RCF 1/8W 1.2M 5% ATS R64
2 4701-153J-2 RCF 1/8W 15K 5% AT R48,52
1 4701-162J-2 RCF 1/8W 1.6K 5% AT R56
8 4701-222J-2 RCF 1/8W 2.2K 5% AT R12,13,35,36,49,53,66,68
1 4701-224J-2 RCF 1/8W 220K 5% AT R78
1 4701-225J-2 RCF 1/8W 2.2M 5% AT R65
6 4701-273J-2 RCF 1/8W 27K 5% AT R17,22,40,45,51,55
4 4701-303J-2 RCF 1/8W 30K 5% AT R1,24,50,54
2 4701-334J-2 RCF 1/8W 330K 5% AT R7,30
1 4701-391J-2 RCF 1/8W 390R 5% AT R57
2 4701-471J-2 RCF 1/8W 470R 5% AT R63,74
4 4701-472J-2 RCF 1/8W 4.7K 5% AT R58,59,69,72
1 4701-563J-2 RCF 1/8W 56K 5% AT R77
2 4701-682J-2 RCF 1/8W 6.8K 5% AT R14,37
1 4701-683J-2 RCF 1/8W 68K 5% AT R67
2 4701-912J-2 RCF 1/8W 9.1K 5% AT R4,27
4 4718-101J-C-X RMF 1W 100R 5% ATS METAL OXIDE R8,9,31,32
1 4750-5510-0 VR 20KBX2 VR16G20K15B20K L=15MM VR1
