7
POWERED SUBWOOFER
PARTS LIST
PRE AMP SECTION
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
1 4750-5520-0 VR 20KAX1 VR16N20K15A20K L=15MM VR2
1 4750-5530-0 VR 10KBX1 VR16N20K15B10K L=15MM VR3
1 4837-3V36-2 DZ 1/2W +-5% 3.3V TEMIC Z3
2 4837-5V16-2 DZ 1/2W 5.1V "TEMIC" AT Z1,2
2 4840-8060-2 DIODE 1N4148 NS D1,2
3 4860-8710-5 TR 9012H Q3,4,7
4 4860-8720-5 TR 9013H SAMSUNG Q1,2,5,6
1 5200-3281-0-06 SW COMAX SK-22D01-SG6-T-NS-IK SW1
1 7010-2221-0 3 PIN SHIELD WIRE ASSY L=130MM CN1
1 7010-2222-0 3 PIN FLAT CABLE ASSY L=100MM CN2
2 8910-0042-0 CE 50V 300UF RL 10% NON-POLARITY C6,14
1 1723-779A-0002 PCB POWER AMP REV:E FC310C
2 150F-101K-5-IEA CC 50V 100PF 10% RL 5X3 C37,38
2 150F-104M-N-FD CC 50V 0.1µF 20% RLF C50,51
1 150F-224M-N-II CC 50V 0.22µF 20% RLF MONO C59
1 150F-334M-N-JJA CC 50V 0.33µF 20% RLF MONO C36
1 150F-470K-5-IEA CC 50V 47PF 10% RL 5X3 C35
2 150F-681J-5-OI CC 50V 680PF 5% RL 8X5 C40,41
2 150H-472M-5-IE CC 100V 4700PF 20% RL 5X3 TEC C60,61
1 153H-102K-5-INA CM 100V 0.001µF 10% RL 5X7.5 C34
1 153H-103K-5-KNA CM 100V 0.01µF 10% RL 6X7.5 C31
2 153H-104K-5-QUA CM 100V 0.1µF 10% RL 9X11 CENTRALAB C54,55
1 153H-224K-5-VYA CM 100V 0.22µF 10% RL 11.5X13 C45
1 153H-333K-5-MRA CM 100V 0.033µF 10% RL 7X9.5 C32
2 157D-227M-5-KW CE 16V 220µF 20% RL 6x12 C52,53
2 157E-106M-5-IU CE 25V 10µF 20% RL 5x11 C44,48
2 157F-105M-5-IU CE 50V 1µF 20% RL 5x11 C33,46
2 157F-107M-5-OW CE 50V 100µF 20% RL 8x12 C42,43
1 157F-225M-5-IU CE 50V 2.2µF 20% RL 5x11 C39
1 157F-474M-5-IU CE 50V 0.47µF 20% RL 5X11 C49
2 157Q-476M-5-LUA CE 35V 47µF 20% RL 6.5X11 ELNA C47,58
POWER AMP SECTION
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART NO DESCRIPTION LOCATION
