8
POWERED SUBWOOFER
PARTS LIST
POWER AMP SECTION
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART NO DESCRIPTION LOCATION
1 1806-2393-0 TT-9904 LE 1012A 1X12TX6MM SPRING COIL L1
3 2101-1231-0 SPADE TERMINAL 6.3X0.8 STRAIGHT AC1,AC2,VO
1 2954-3014-3000 B-TITE 3X14MM(BLK.ZN) D11
1 3130-3020-0 IC LM7915CT REGULATOR U13
1 3130-3030-0 IC LM7815CT REGLATOR U12
1 3130-3550-0 IC TA7317P U11
1 3130-4080-0 IC TL072CP DUAL FET OP AMP TI U10
1 3131-6140-0 IC BA4560 ROHM U9
2 4132-1551-0 TERMINAL OUT PUT SPK+, SPK-
1 4500-8090-0 RELAY RUDH-SH-124D "GOOD SKY" PLY1
5 4701-101J-2 RCF 1/8W 100R 5% AT R102,103,106,108,109
1 4701-102J-2 RCF 1/8W 1K 5% AT R88
5 4701-103J-2 RCF 1/8W 10K 5% AT R90,91,92,,115,118
4 4701-104J-2 RCF 1/8W 100K 5% AT R80,81,116,117
3 4701-105J-2 RCF 1/8W 1M 5% AT R82,83,87
1 4701-123J-2 RCF 1/8W 12K 5% AT R101
2 4701-153J-2 RCF 1/8W 15K 5% AT R94,96
1 4701-183J-2 RCF 1/8W 18K 5% AT R120,123
1 4701-222J-2 RCF 1/8W 2.2K 5% AT R84
1 4701-272J-2 RCF 1/8W 2.7K 5% AT R100
1 4701-274J-2 RCF 1/8W 270K 5% AT R93
2 4701-333J-2 RCF 1/8W 33K 5% AT R99,121
2 4701-391J-2 RCF 1/8W 390R 5% AT R97,98
1 4701-392J-2 RCF 1/8W 3.9K 5% AT R86
1 4701-472J-2 RCF 1/8W 4.7K 5% AT R129
1 4701-562J-2 RCF 1/8W 5.6K 5% AT R130
3 4701-563J-2 RCF 1/8W 56K 5% AT R114,119,122
1 4701-682J-2 RCF 1/8W 6.8K 5% AT R85
1 4701-822J-2 RCF 1/8W 8.2K 5% AT R131
1 4707-751J-2 RCF 1/2W 750R 5% AT R124
4 4718-100J-C-X RMF 1W 10R 5% ATS METAL OXIDE R104,105,112,113
2 4719-101J-C-X RMF 2W 100R 5% ATS METAL R127,128
2 4719-222J-1-X RMF 2W 2.2K 5% AL METAL OXIDE R125,126
2 474B-0R1J-1 RWR 5W 0.1 5% AL R110,111
1 4756-1036-3-15 SVR B1OK H3 NVZ6TL1 6.3X6.8 HDK TP1
1 4756-2026-3-05 SVR B2K H3 NVZ6TL1 HDK TP2
2 4804-0010-2 DIODE 1N4001 AT D10,12
1 4840-0350-0 DIODE BRIDGE RECT. RS603 D11
6 4840-8060-2 DIODE 1N4148 NS D3,4,5,6,13,14
