4 I ENGLISH
C. SPECIFICATIONS
SKU 44308-B
Camera sensor size 5 MP | 1/3.2”
Stand Professional stand with adjustable height
Lens 5 element IR cut , high quality GLASS /EFL(Equivalent Focal Length): 15.8 mm /FOV: 13.0”
Focuser range 10 mm to infinity
Illuminator Upper ring- 8 bright white adjustable LEDs
Magnification 20x to 200x
Shutter trigger In software
Still Image resolution 2592x1944 (5MP), 2320x1744 (4MP), 2048x1536 (3MP), 1920x1080 (2MP),
1280x1024 (1.3MP)
Video resolution Min. 1280x1024 @15fps; Max. 2592x1944 @10fps
Computer interface 2.0 USB
Software Celestron Micro Capture Pro (with measuring and note taking features)
Operating systems supported Windows: Windows 7/8/10
Mac: 10.14 and higher
Software languages (12) English, German, French, Spanish, Russian, Italian, Portuguese, Dutch, Polish,
Japanese, Korean and Chinese
Minimum system requirements 512MB RAM/ 64M Video Memory/ Open USB port/ CD-ROM Drive
Dimensions Microscope: 110x35 mm (4.33”x1.38”)
Stand: 175x140x110 mm (6.90”x5.51”x4.33”)
Weight 2 lbs. ( 907 grams) {including base and packaging}
2. SETUP
A. ASSEMBLE THE MICROSCOPE STAND
+
Carefully remove all components from the box.
+
Slide the Shaft Connection Lock Collar (6) onto the Support Shaft (10).
+
Attach the Shaft Connection Lock Collar (6) to base threads and tighten.
10.
6.
NOTE: Software operating systems change quickly. Refer to the web page for latest software downloads and compatibility
