6 I ENGLISH
A. CONNECTING
+
Connect the microscope to your computer via the USB
2.0 cable.
+
Click on the Micro Capture Pro desktop icon
to launch the software.
+
Your microscope should automatically connect and begin
streaming images.
NOTE: If the microscope is not connected to the USB port, the following error
message will be displayed: “No device detected. Please connect your
microscope directly to an open USB port.”
B. FOCUSING
+
Now, rotate the Focus Wheel (3) to set the fine focus.
3. USING YOUR MICROSCOPE
1.
1.
3.
4.
4.
2.
2.
+
Turn the Height Adjustment Wheel (2) to set the coarse focus.
+
To focus on an image using the included stand:
+
Adjust the height of the carriage holding the microscope.
+
Tighten the Carriage Height Adjustment Lock Nut (4) to
hold in place.
+
Once satisfied with the position, tighten the Lock Wheel
(1), securing the carriage in place.
