Series PS-50/60
49-MCEPS56EN03 USER´S MANUAL
1
1. INTRODUCTION
NOTE: These scales are not allowed for the uses mentioned in paragraph 2a of the article 1
st
of the Directive
90/384/CE, therefore they are not valid for commercial transactions
The series PS-50/60 offers a precise, rapid and versatile only-weight scales for all uses. There are 3
weighing scales models in this range. The platform size is 190mm x 230mm, and the capacity ranges from 3
kg to 15 kg.
All keypads are sealed, membrane switches are colour-marked and displays are easy-to-read, large-sized
liquid crystal displays (LCDs). The LCDs are equipped with a backlight.
All units include tare, zero, change unit of weight, change division function.
Weighing scales series PS-60 is equipped with dust and liquid protection equivalent to IP-68.
2. SPECIFICATIONS
PS-50/60 SERIES
Model no.
PS-50/60-3 PS-50/60-6 PS-50/60-15
Range
3kg
6kg 15kg
Step 1g/0.5g 2g/1g 5g/2g
Resolution 1/3,000 or 1/6,000
Maximum tare 3kg 6kg 10kg
Minimum weight 20g/10g 40g/20g 100g/40g
Plate size 190mm x 230mm
Units of weight kg
Optional functions Beeper, backlight, stainless steel plate
3. INSTALLATION
3.1. GENERAL INSTALLATION
The scales should be placed on a firm, even surface.
Avoid extreme temperatures. Do not place the scales in direct sunlight or near air conditioning vents.
Avoid unstable tables. The tables and the ground should be firm and not vibrate. Do not place the scales
near vibrating machinery.
Avoid unstable electricity sockets. Do not use the scales near equipment with high electrical power
consumption such as soldering equipment or large motors.
Avoid high humidity that can cause condensation. Do not submerge the scales in water.
Avoid draughts such as those from fans or open doors. Do not place the scales near open windows.
Keep the scales clean.
Do not stack anything on the scales when they are not in use.
