CEM DT-932N - Diode Test Specifications; Diode Test Parameters and Accuracy; Audible Continuity Specifications; Continuity Check Parameters

10
Diode Test
Test current
Resolution
Accuracy
0.3mA
typical
1 mV
+10% of rdg + 5 dgts
Open circuit voltage: 1.5V dc typical
Overload protection: 600V dc or ac rms.
Audible continuity
Audible threshold: Less than 100Ω; Test current: <0.3mA
Overload protection: 600V dc or ac rms.
OPERATION
WARNING: Risk of electrocution. High-voltage circuits,
both AC and DC, are very dangerous and should be measured
with great care.
1. ALWAYS turn the function switch to the OFF position when
the meter is not in use. This meter has Auto OFF that
automatically shuts the meter OFF if 15 minutes elapse between
uses.
2. If “OL” appears in the display during a measurement, the
value exceeds the range you have
selected. Change to a
higher range.
