Make sure the dies are exactly positioned on the desired crimp point otherwise re-
open dies following instructions as per § 2.5 and reposition the connector.
2.3) Compression
– By keeping operating button (10) pressed, the motor continues to operate: the ram will
gradually move forward until the two dies touch.
– It is recommended to continue pumping until the maximum pressure valve is activated
and a "click" is heard.
– The motor will continue to operate after the maximum pressure relief valve has activated.
No further crimping force is applied, the oil is bypassed and returned to the reservoir.
2.4) Head rotation
For ease of operation, the tool head can rotate through 180°, allowing the operator to work
in the most comfortable position.
Warning: do not attempt to rotate the head when the hydraulic circuit is pressurised.
2.5) Release of dies
By pressing the pressure release lever (201) located below operating button (10), the ram
will retract and open the dies.
2.6) Battery status (Ref. to Fig. 4)
After releasing the operating button, the residual battery
capacity is automatically displayed for 5 seconds on the
indicator (15).
The number of LEDs illuminated indicates the residual
capacity:
10 LEDs illuminated: fully charged
5 LEDs illuminated: 50 % capacity
1 LED illuminated: minimum charge
When replacing the battery, press the two points marked with the word "PUSH" at the
same time, remove the fl at battery from its housing and insert the new one.
3. WARNING
Before starting work on electrical equipment, please ensure that either there are no live
parts in the immediate working area or that precautions are taken for working near live
parts in accordance with EN50110-1.
DO NOT USE THIS TOOL ON OR NEAR ENERGIZED CONDUCTORS WITHOUT PROPER
PERSONAL PROTECTIVE EQUIPMENT. FAILURE TO OBSERVE THIS WARNING COULD
RESULT IN SEVERE INJURY OR DEATH.
FIG. 4
%
15
ENGLISH
5
30
Code N°
N°code
Art.-Nr.
N°código
N°codice
DESCRIPTION / DESIGNATION / BESCHREIBUNG /
DESCRIPCION / DESCRIZIONE
Qty
Q.tè
Menge
C.dad
Q.tà
Item
Pièce
Teil
Elemento
Componente
6640205 72 WASHER / RONDELLE / SCHEIBE / ARANDELA / ROSETTA DENTATA M4 4 K
6250084 73 TIE / COLLIER / BINDER / ABRAZADERA / FASCETTA 1
6362021 74 SEAL / JOINT / DICHTUNG / JUNTA DE GOMA / GUARNIZIONE 2 K
6362007 75 SEAL / JOINT / DICHTUNG / JUNTA DE GOMA / GUARNIZIONE 1 K
6340720 76 GRUB SCREW / VIS SANS TETE / IMBUSSCHRAUBE / TORNILLO / GRANO 1
6020020 77 PIN / AXE / STIFT / PERNO / PISTONC. SBLOCCO PRESSIONE 1
6361881 78 O-RING / JOINT TORIQUE / O-RING / JUNTA DE GOMA / GUARNIZIONE OR 1 K
6360120 79 O-RING / JOINT TORIQUE / O-RING / JUNTA DE GOMA / GUARNIZIONE OR 1 K
6000385 80 BUSH / DOUILLE / BUCHSE / CASQUILLO / CAMICIA 1
6860012 200 COMPL.HEAD / TETE COMPL. / KOMPL.KOPF / CABEZA COMPL. / TESTA COMPL. 1
6780150 200 39
HEAD SUPPORT / SUPPORT TETE / KOPFHALTER / SOPORTE CABEZA / SUPPORTO
TESTA
1
6520482 200 40 SPRING / RESSORT / FEDER / MUELLE / MOLLA 1
6370270 200 41 LATCH / CROCHET / HAKEN / GANCHO / GANCIO SUPP.MATRICI 1
6780133 200 42
UPPER DIE HOLDER / SUPPORT MATRICE / PRESSEINSATZHALTER / SOPORTE MATRIZ /
SUPPORTO MATRICE
1
6520403 200 46 SPRING / RESSORT / FEDER / MUELLE / MOLLA 1
6740020 200 83 BALL / BILLE / KUGEL / BOLA / SFERA 1/4" 1
6520942 200 84 SPRING / RESSORT / FEDER / MUELLE / MOLLA 1
6340138 200 85 GRUB SCREW / VIS SANS TETE / IMBUSSCHRAUBE / TORNILLO / GRANO M8x6 1
6560370 200 86 PIN / AXE / STIFT / PERNO / PERNO 2
6040725 200 87 CIRCLIP / ANNEAU ELAST. / FEDERRING / ANILLO ELAST. / ANELLO ELAST. D.9 2
6440117 201
PRES.RELEASE LEVER / GACHETTE DE DECOMPR. / DRUCKABLASSHEBEL / PALANCA DE
DESBL.PRESION / LEVA SBLOCCO PRESSIONE
1
6000523 202
COMPLETE HOUSING / CARTER COMPLET / KOMPLETTES GEHÄUSE / CARCASA
COMPLETA / CARTER COMPLETO
1
6760001 202 11 PIN / GOUPILLE / STIFT / PASADOR / SPINA CILINDRICA D.2X10 2
6000310 202 16
COMPL.MOTOR / MOTEUR COMPL. / KOMPL.MOTOR / MOTOR COMPL. / MOTORE
COMPLETO
1
6000328 202 17 WASHER / RONDELLE / SCHEIBE / ARANDELA / RALLA 1
6900181 202 18 SCREW / VIS / SCHRAUBE / TORNILLO / VITE M4x10 4
6000364 202 19 GEAR / ENGRENAGE / GETRIEBE / ENGRANAJE / INGR.SATELLITE 3
6000363 202 20 GEAR / ENGRENAGE / GETRIEBE / ENGRANAJE / INGR.SATELLITE 3
6000323 202 21 GEAR / ENGRENAGE / GETRIEBE / ENGRANAJE / RUOTA A DENT.INTERNA 1
6000321 202 22 GEAR / ENGRENAGE / GETRIEBE / ENGRANAJE / PIGNONE MONTATO 1
6000315 202 23 WASHER / RONDELLE / SCHEIBE / ARANDELA / RONDELLA SPESS. 0.2 6
6700520 202 26 CIRCLIP / ANNEAU ELAST. / FEDERRING / ANILLO ELAST. / ANELLO ELAST. 1
6000392 202 29 BEARING / ROULEMENT / KUGELLAGER / COJINETE / GABBIA 1
6040682 202 32 RING / ANNEAU / RING / ANILLO / ANELLO IR 7X10X12 1
6220198 202 47 SPACER / ENTRETOISE / ZWISCHENSTÜCK / DISTANCIADOR / DISTANZIALE 2
6640205 202 70 WASHER / RONDELLE / SCHEIBE / ARANDELA / ROSETTA DENTATA M4 4
6040686 202 71 RING / ANNEAU / RING / ANILLO / ANELLO IR 20x25x16 1
6000336 202 203 ECCENTRIC / EXCENTRIQUE / EXENTER / EXCENTRICO / ECCENTRICO 1
6000525 202 204 HOUSING / CARTER / GEHÄUSE / CARCASA / CARTER 1
6160054 205 BODY / CORPS / KÖRPER / CUERPO / CORPO 1
