Page 8 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 57015
EF;6GH IJ6KFGLIM NFLMG6MFMO6FEE6NPQH
O.,(3"83%P,$$*(Z%L8#$,77*9%"8%!*."47*
F%EJFKc%M6FK%PFGG6KH%NFH%OFVE6%PFGG6KH%6dJQIELIM1%%
GI%K6TVO6%KLEc%I;%F%EJFKc%M6FK%PFGG6KH%;IQQIR%GW6E6%LMEGKVOGLIME%6dFOGQH1
GI%JK6!6MG%E6KLIVE%LM^VKH-%
R*,(%FMEL?,//(&_*9%#/7,#.?(*#"#$,8$%#,2*$Z%3&337*#%,89%.*,_Z?9'$Z%('++*(%)&(`%37&_*#%
).*8*_*(%4&88*4$"83=%9"#4&88*4$"83=%&(%)&(`"83%8*,(%+,$$*(Z1%%%
P,$$*(Z%,4"9%4,8%4,'#*%/*(5,8*8$%+7"898*##1
1. Position AC and DC cables to reduce risk of
damage by hood, door, or moving engine part.
2. Stay clear of fan blades, belts, pulleys, and
other parts that can cause injury to persons.
3. Check polarity of battery posts. POSITIVE
(POS, P, +) battery post usually has larger
diameter than NEGATIVE (NEG, N,–) post.
4. Determine which post of battery is grounded
(connected) to the chassis. If negative post is
grounded to chassis (as in most vehicles), see 5.
If positive post is grounded to the chassis, see 6.
5. For negative-grounded vehicle, connect
POSITIVE (RED) clip from battery charger to
POSITIVE (POS, P, +) ungrounded post of battery.
Connect NEGATIVE (BLACK) clip to vehicle
chassis or engine block away from battery.
Do not connect clip to carburetor, fuel lines, or
sheet-metal body parts. Connect to a heavy
gauge metal part of the frame or engine block.
6. For positive-grounded vehicle, connect
NEGATIVE (BLACK) clip from battery charger
to NEGATIVE (NEG, N, –) ungrounded post of
battery. Connect POSITIVE (RED) clip to vehicle
chassis or engine block away from battery.
Do not connect clip to carburetor, fuel lines, or
sheet-metal body parts. Connect to a heavy
gauge metal part of the frame or engine block.
7. When disconnecting charger, turn switches to
off, disconnect AC cord, remove clip from vehicle
chassis, and then remove clip from battery terminal.
8. After use clean, then store the charger
indoors out of children’s reach.
O.,(3"83%P,$$*(Z%I'$#"9*%!*."47*
F%EJFKc%M6FK%PFGG6KH%NFH%OFVE6%PFGG6KH%6dJQIELIM1%%
GI%K6TVO6%KLEc%I;%F%EJFKc%M6FK%PFGG6KH%;IQQIR%GW6E6%LMEGKVOGLIME%6dFOGQH1
GI%JK6!6MG%E6KLIVE%LM^VKH-%
R*,(%FMEL?,//(&_*9%#/7,#.?(*#"#$,8$%#,2*$Z%3&337*#%,89%.*,_Z?9'$Z%('++*(%)&(`%37&_*#%
).*8*_*(%4&88*4$"83=%9"#4&88*4$"83=%&(%)&(`"83%8*,(%+,$$*(Z1%%%
P,$$*(Z%,4"9%4,8%4,'#*%/*(5,8*8$%+7"898*##1
1. Check polarity of battery posts. POSITIVE
(POS, P, +) battery post usually has a larger
diameter than NEGATIVE (NEG, N, –) post.
2. Attach at least a 24-inch-long 6-gauge
(AWG) insulated battery cable to
NEGATIVE (NEG, N, –) battery post.
3. Connect POSITIVE (RED) charger clip to
POSITIVE (POS, P, +) post of battery.
4. Position yourself and free end of cable as far away
from battery as possible – then connect NEGATIVE
(BLACK) charger clip to free end of cable.
5. Do not face battery when making final connection.
6. When disconnecting charger, always do
so in reverse sequence of connecting
procedure and break first connection while
as far away from battery as practical.
7. After use clean, then store the charger
indoors out of children’s reach.
