Page 14 For technical questions, please call 1-888-866-5797. Item 63423
SAFETY OPERATION MAINTENANCEASSEMBLY
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List and Diagram
Parts List
Part Description Qty
1 Handle 1
2 Handle Cover 1
3 Transformer 1
4 nut 7
5 Cable Storage Peg 2
6 Main Housing 1
7 Power Cable 1
8 Interior Control Panel 1
9 Tapping Screw 5
10 Fixing Plate 4
11 Exterior Control Panel 1
12 nut 9
13 Fan 1
14 Right Housing 1
15 Tapping Screw 12
16 Wheel 2
17 Hubcap 2
18 Power Switch 1
19 Hex Bolt, Spring Washer & Washer Set 1
Part Description Qty
20 SCR Clip 3
21 Press Plate 1
22 Rectifier Bridge 1
23 Hex Column 1
24 Main Board 1
25 nut 2
26 Adjustment Screw 2
27 Tapping Screw 6
28 Tapping Screw 4
29 Tapping Screw 13
30 Foot 1
31 Hex Bolt, Spring Washer & Washer Set 4
32 Black Negative Cable 1
33 Bracket 2
34 Red Positive Cable 1
35 Axle 1
36 Left Housing 1
37 Wheel Bearing 2
38 Screw 16
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts. Internal parts are not user-serviceable
and are not available. Specify UPC 792363634236 when ordering parts.
