Center 265 - AC V Measurement

Center 265 True RMS Leakage Current Clamp Meter
9
Fig.2 Measuring out of balance leakage current:
3-Phase 3-Wire system Single-Phase 2-Wire system
6-2 AC V Measurement：
WARNING!
Maximum Input Voltage is 300V AC/DC. Do not attempt to
Take any voltage measurement that may exceed this
maximum to avoid Electrical shock hazard and/or damage to
this instrument.
Switch the main function selector
to range.
Connect the red test lead to
the "+ ” terminal and the black
lead to the “COM”terminal.
Measure the voltage by touching
the test lead tips to the test circuit
where the voltage measurement is
required.
Read the result from the LCD
display.
