Central Hydraulics 2792 - Parts Lists and Diagrams; Main Parts List

SKU 2792 For technical questions, please call 1-800-444-3353. Page 8
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/
OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD
BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE
BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LISTS AND DIAGRAMS
Main Parts List
Part DESCRIPTION Qty.
1 BOLT M12X90 4
2 NUT M12 10
3
Rubber Pad 2
4 FRONT LIFT ARM 1
5 REAR LIFT ARM 1
6 WASHER 8
7 BOLT 2
8 WASHER 10 3
9 STOP BAR 1
10 NUT M10 2
11 LIFTING FRAME 1
12 HANDLE ASS’Y 1
13 PIN 1
15 PIN 3.2X20 1
16 BOTTLE JACK 1
17 FOOT PEDAL 1
18 RELEASE PEDAL 1
19 SCREW M6X35 1
Part DESCRIPTION Qty.
20 BOLT M8X15 2
21 SPRING 1
22 Swivel Caster 2
23 WASHER 12 2
24 NUT M12 2
25 LOCK BOLT ASS’Y 2
26 BOLT M12X65 4
27 FRONT WHEEL 2
28 BOTTOM BASE 1
29 BOLT M12X65 2
30 BUSHING 2
31 PIN 1
32 SCREW M5X10 1
33 SPLIT COTTER PIN 1
34 GRIP
2
35 Pin 3.2 x 36 1
36 Bolt M5 x 25 1
37 Pin 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not avail-
able individually as replacement parts.
Rev 04c, 10c
