Page 2SKU 37555
SPECIFICATIONS
Jack Capacity 3 T (The lift cannot support this much.)
Winch Cable 1/4” steel, 25’ long with locking hook
Boom Length 53-1/2”
Boom Height 80” from base
Post Pivots 360°
Ram Travel 5”
Base 7-3/8” x 9-1/2”, 1/2” thick steel
SAVE THIS MANUAL
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
SAFETY WARNINGS AND PRECAUTIONS
WARNING: When using winch, basic safety precautions should always be followed to re-
duce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Always wear ANSI approved impact safety goggles when operating the winch.
2. Donotexceedwinchloadweightcapacity(seespecications).
3. Be certain winch is properly bolted to a truck bed that can hold the winch load.
4. Always use proper couplings when connecting winch cable hook to load cable or
rope.
5. Donotoverloadthewinch.Staywithinthecapacitylevelsshowninthespecications.
6. Do not use inappropriate attachments to extend the length of the winch cable.
7. Never lift people or hoist loads over people.
8. Never come between the winch and the load when operating.
9. Do not apply load to winch when cable is fully extended. Keep at least 4 full turns of
cable on the reel.
10. After moving an item with the winch, secure the item. Do not rely on the winch to hold
it for an extended period. The winch does not have a locking key.
11. Examine winch before using. Components may be affected by exposure to chemicals,
salts, and rust.
12. Never fully extend cable while pulling a load. Keep 4 complete turns of cable around
the winch spool.
13. Never operate winch if cable shows any signs of weakening, is knotted or kinked.
14. Never fully extend the cable while under load.
Capacity(lb.) Boom Length Hole
500 53 1/2” 1
600 47” 2
700 40 1/2” 3
1000 33 1/2” 4
REV 08g
