TROUBLESHOOTING GUIDE
Turntable rotates in only one direction.
Reverse Pedal (59E) broken. Check entire Reverse Assembly.
Turntable does not rotate.
Belt (16D) broken. Replace Belt
Reverse Pedal (59E) broken. Check entire Reverse Assembly.
Problem with Motor (10D). Check for loose wires in the Motor,
Plug, or Socket. Replace Motor.
Turntable locks while mounting/removing tire.
Belt loose. Adjust Belt Tension.
Jaws (17C) slow to open/close.
Silencer (36 E) clogged. Clean or replace Silencer.
Turntable does not lock the wheel rim correctly.
Jaws worn. Replace Jaws.
Defective Piston (26C). Replace Plate Cylinder Gaskets (23C).
Tool touches the wheel rim during tire mounting/removing process.
Locking Plate (12C) incorrectly Adjust, or replace Locking Plate.
adjusted or defective.
Plate Locking Screw (14C) loose. Tighten Screw.
Bead Breaker Pedal and Jaw Clamp Pedal lock out of position.
Return Spring (24E) broken. Replace Spring.
Bead breaking operation difcult.
Silencer (36E) clogged. Clean, or replace Silencer.
Valve Shaft O-Ring (31E) broken. Replace O-Ring.
WARNING:
For your safety, major service and repair procedures should be performed by a qualied
technician. Replace or repair damaged or worn parts immediately. Use only identical
replacement parts. Only use accessories intended for use with this product. Approved
accessories are available from Harbor Freight Tools.
