Page 7For technical questions, please call 1-800-444-3353.Item 40131
Part Description Qty
1 Base 1
2 Stand 1
3 Fixed Washer 1
4 Washer 1
5 Position Sleeve 1
6 Flange A 1
7 Sleeve 1
8 Flange B 1
9 Position Sleeve 1
10 Washer 1
11 Spring 1
12 Washer 1
13 Swivel (2 valves & O-rings) 1
Part Description Qty
14 Spring Washer 1
15 Nut 3
16 Washer 3
17 Rubber Protector 1
18 Clamp 1
19 Screw 3
20 Screw 3
21 Washer 3
22 Nut 3
23 Handle 1
24 Input Valve 1
25 Locking Pin 1
26 Hose 1
Parts List and Diagram
Record Product's Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
８
２２
２３
１１
１２
１３
１４
１９
１５
１０
９
２０
１７
２６
２４
７
６
２５
５
４
３
２
１
１６
１８
２１
SAFETYOPERATIONMAINTENANCE SETUP
