SKU 40400 For technical questions, please call 1-800-444-3353. Page 7
Parts List
Part Description Qty Part Description Qty
1 Socket Screw 4 30 Capacitor 1
2 Cylinder Head 1 31 Back Cover 1
3 Cylinder Head Gasket 1 32 Forced Air Fan 1
4 Valve 1 33 Stem Ring 1
5 Cylinder Gasket 1 34 Shroud 1
6 Cylinder 1 35 Stem Ring 2
7 Gasket 1 36 Pin 2
8, 8-1 Compression Ring 2 37 Strip Valve 1
8-2 Piston 1 38 Filter/Filter Screw 1
9 Wrist Pin Piston 1 39 Elbow, 90° 1
10 Piston 1 40 Drain Tube 1
11 Hex Head Nut 1 41 Check Valve 1
12 Crossed Screw 4 42 Tube 1
13 Handle 1 43 Drain Valve 1
14 Oil Retainer 1 44 Regulated Valve 1
15 Connecting Rod 1 45 Outlet 1
16 Gasket Crankcase 1 46 Air Pressure Switch 1
17 Hex Head Bolt 6 47 Air Pressure Meter 1
18 End Cover Assembly 1 48 Air Pressure Meter 1
19 Washer 1 49 Safety Valve 1
20 Oil Sight 1 50 Tank Assy 1
21 Stem Ring 1 51 Bolt 1
22 Washer 1 52 Rubber Foot 1
23 Crankshaft Cone Assy 1 53 Petcock 1
24 Inner Hex Head Bolt 1 54 Axle 2
25 Crank Case 1 55 Wheel 2
26 Cross-head Self-tapping Screw 1 56 Washer 2
27 Motor Drive 1 57 Lock Washer 2
28 Nut 1 58 Nut 2
29 Washer 1 59 Overload Protection 1
30 Capacitor 1 60 Washer 1
61 Nut 1
Note: Some parts listed and shown on this page are for illustration purposed only and are not
available individually as replacement parts.
