Page 18 For technical questions, please call 1-800-444-3353. Item 46719
NOTICE
Clean the Spray Gun IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Spray Gun.
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Nozzle 1
2 Lock Ring 1
3 Ring Washer 1
4 Seal Ring 1
5 Fluid Nozzle 1
6 Spacing Ring 1
7 Needle Seal Screw 1
8 Needle Seal Gasket 3
9 Gun Body 1
10 Snap Ring Ø3.5 1
11 Needle Pin 1
12 Trigger Pin 1
13 Trigger 1
14 Snap Ring Ø4 1
15 Filter Connection 1
16 Gasket 1
17 Screw 1
18 Cup 1
19 Lid 1
20 Needle 1
21 Needle Spring 1
22 Fluid Control Knob 1
Part Description Qty
23 Needle Screw 1
24 Snap Ring Ø2.5 1
25 O-Ring Ø2.8 x Ø1.8 1
26 Pattern Adjustment Seat 1
27 Pattern Adjustment Screw 1
28 Pattern Adjustment Knob 1
29 Bolt M2.5 x 5 1
30 Spring 1
31 Valve Shaft 1
32 Valve Gasket 1
33 Air Valve 1
34 O-Ring Ø5 x Ø1.5 1
35 Washer 1
36 Screw 1
37 Adjusting Valve 1
38 Spring 1
39 Gasket 1
40 O-Ring Ø2.8 x Ø1.8 1
41 Air Control Knob Seat 1
42 Air Control Knob 1
43 Air Connector 1
44 Air Regulator 1
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Parts List and Diagram
Parts List
