ASSEMBLY and OPERATING

INSTRUCTIONS

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our Web site at http://www.harborfreight.com

®

Copyright

©

2005 by Harbor Freight Tools

®

. All rights reserved. No portion of this manual or any

artwork contained herein may be reproduced in any shape or form without the express written

consent of Harbor Freight Tools.

For technical questions and replacement parts, please call 1-800-444-3353.

TO PREVENT SERIOUS INJURY,

READ AND UNDERSTAND ALL WARNINGS

AND INSTRUCTIONS BEFORE USE.

Due to continuing improvements, actual product may differ slightly from the product described herein.

HVLP SPRAY GUN KIT

93305

Table of Contents

Questions and Answers:

A
Anna CoxAug 8, 2025
How to fix fluid tip leakage in Central Pneumatic 93305 Paint Sprayer?
- A
  ashleylewisAug 8, 2025
  If you're experiencing fluid tip leakage with your Central Pneumatic Paint Sprayer, there are several potential causes. The tip might be dirty, so try cleaning it. The packing nut could be too tight, so loosen it slightly. A broken fluid needle spring could also be the culprit, requiring a replacement. Lastly, the tip could be worn or damaged, in which case you should replace the tip and/or needle.
S
Sara FosterAug 13, 2025
Why is my Central Pneumatic Paint Sprayer sputtering?
- R
  Raymond ThompsonAug 13, 2025
  Sputtering spray from your Central Pneumatic Paint Sprayer can occur for several reasons. It may be due to a low material level (refill the cup), the cup being tipped too far (hold it upright), a clogged air vent (clean the vent hole), loose fluid inlet connections (tighten them), a dry or loose fluid needle packing nut (lubricate and/or tighten), or a loose/damaged fluid tip/seat (adjust or replace it).
M
Mrs. Kristie Fernandez MDAug 18, 2025
What to do if Central Pneumatic 93305 will not spray?
- S
  Steven SmithAug 18, 2025
  If your Central Pneumatic Paint Sprayer won't spray, several factors could be at play. First, check the air hoses to ensure there's pressure at the gun. Also, make sure the fluid control is open enough. Finally, the fluid might be too thick; try thinning it or increasing the pressure, staying within the maximum range.
C
Carol BakerAug 23, 2025
Why Central Pneumatic Paint Sprayer has overspray?
- P
  Pamela MorenoAug 25, 2025
  Overspray with your Central Pneumatic Paint Sprayer can be attributed to a few reasons. You might be applying the paint too quickly, so move moderately and parallel to the surface. The distance from the workpiece could be incorrect, so adjust it accordingly. Also, excessive air pressure can cause overspray, so reduce the air pressure.
L
Laura AcostaAug 28, 2025
What causes air leaking from air cap on Central Pneumatic Paint Sprayer?
- F
  fullertiffanyAug 28, 2025
  Air leaking from the air cap of your Central Pneumatic Paint Sprayer could be due to a few reasons: a dirty air valve/seat (clean it), a sticking air valve (lubricate it), a damaged air valve spring (replace it), a worn/damaged air valve/seat (replace it), or a bent valve stem (replace it).
K
Kimberly BallardSep 2, 2025
How to stop fluid leaking from packing nut on Central Pneumatic 93305?
- R
  Robert ChambersSep 2, 2025
  If fluid is leaking from the packing nut of your Central Pneumatic Paint Sprayer, it could be due to a loose packing nut. Try tightening it without restricting movement. Alternatively, the packing may be worn or dry, in which case you should replace or lubricate it with a non-silicone lubricant.

Central Pneumatic 93305 Specifications

General

Nozzle Size	1.4 mm
Cup Capacity	20 oz
Tip Size	1.4 mm
Type	HVLP
Operating Pressure	50 PSI
Maximum Flow Rate	4.5 CFM
Power Source	Pneumatic

Summary

Specifications

Safety Warnings and Precautions

Air Connection

Recommended Air Line Components

Lists recommended components for air line setup including regulator and inline filter.

Control Layout

A Comparison: Conventional versus HVLP Spray Guns

Preparation

Fan Direction and Pattern Adjustment

Fan Direction

Instructions on how to change the spray fan direction from horizontal to vertical.

Pattern Adjustment

Guidance on adjusting the spray pattern using control knobs for desired output.

Techniques

Maintenance

SOLVENT SELECTION

Guidelines for selecting appropriate solvents for cleaning the spray gun.

Parts List

Assembly Diagram

Troubleshooting

Spray Pattern Diagnosis

Identifies common spray pattern problems and their likely causes and solutions.

Troubleshooting (continued)
