Page 5F o r t e c h n i c a l q u e s t i o n s , p l e a s e c a l l 1 - 8 8 8 - 8 6 6 - 5 7 9 7 .Item 60637
G r o u n d i n g
T O PREV ENT EL ECT RIC S H O CK AND D EAT H
F RO M INCO RRECT G RO UND ING W IRE CO NNECT IO N:
Ch e c k w i t h a q u a l i f i e d e l e c t r i c i a n i f y o u a r e i n d o u b t a s t o w h e t h e r t h e o u t l e t i s p r o p e r l y g r o u n d e d .
D o n o t m o d i f y t h e p o w e r c o r d p l u g p r o v i d e d w i t h t h e c o m p r e s s o r .
Ne v e r r e m o v e t h e g r o u n d i n g p r o n g f r o m t h e p l u g . D o n o t u s e t h e c o m p r e s s o r i f t h e p o w e r c o r d o r p l u g i s
d a m a g e d . If d a m a g e d , h a v e i t r e p a i r e d b y a s e r v i c e f a c i l i t y b e f o r e u s e . If t h e p l u g w i l l n o t f i t t h e o u t l e t , h a v e a
p r o p e r o u t l e t i n s t a l l e d b y a q u a l i f i e d e l e c t r i c i a n .
1 1 0 - 1 2 0 V AC G r o u n d e d Co m p r e s s o r s : Co m p r e s s o r s w i t h T h r e e Pr o n g Pl u g s
1. In the event of a malfunction or breakdown,
grounding provides a path of least resistance for
electric current to reduce the risk of electric shock.
This compressor is equipped with an electric
cord having an equipment-grounding conductor
and a grounding plug. The plug must be
plugged into a matching outlet that is properly
installed and grounded in accordance
with all local codes and ordinances.
2. Do not modify the plug provided –
if it will not fit the outlet, have the proper
outlet installed by a qualified electrician.
3. Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
The conductor with insulation having an outer
surface that is green with or without yellow
stripes is the equipment-grounding conductor.
If repair or replacement of the electric cord or
plug is necessary, do not connect the equipment-
grounding conductor to a live terminal.
4. Check with a qualified electrician or service
personnel if the grounding instructions are
not completely understood, or if in doubt as to
whether the compressor is properly grounded.
5. Use only 3-wire extension cords that have
3-prong grounding plugs and 3-pole receptacles
that accept the compressor’s plug.
6. Repair or replace damaged or worn cord immediately.
1 2 5 V AC 3 - Pr o n g Pl u g a n d O u t l e t
( f o r u p t o 1 2 5 V AC a n d u p t o 1 5 A)
G r o u n d i n g
Pi n
7. This compressor is intended for use on a
circuit that has an outlet that looks like the one
illustrated above in 1 2 5 V AC 3 - Pr o n g Pl u g
a n d O u t l e t . The compressor has a grounding
plug that looks like the plug illustrated above
in 1 2 5 V AC 3 - Pr o n g Pl u g a n d O u t l e t .
8. The outlet must be properly installed and grounded
in accordance with all codes and ordinances.
9. Do not use an adapter to connect this
compressor to a different outlet.
S y m b o l o g y
PS I
Pounds per square inch of pressure
CF M
Cubic Feet per Minute flow
S CF M
Cubic Feet per Minute flow
at standard conditions
NPT
National pipe thread, tapered
NPS
National pipe thread, straight
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc.
V AC
Volts Alternating Current
A
Amperes
S AF ET YO PERAT IO NM AINT ENANCE S ET UP
