Central Pneumatic 69724 - Parts List and Diagram

Page 14 @+-*)/93='91<*A,/()'+=(B*4</1(/*91<<*CDEEEDE!!DF#"#6 Item 69724
GH@;IJ KL;MHINKO PHNOI;OHOQ;G;IRL
L1-) W/(9-'4)'+= g)]
1 Tank 1
2 Wheel 2
3 Cotter Pin 3
4 Front Foot 1
5 Wheel Axle 1
6 Handle Bar 2
7 Handle Grip 2
8 Pan Screw 4
9 nut 4
10 Safety Valve 1
11 O-Ring 1
12 Filler Cap 1
13 Joint Pipe 1
14 Intake Manifold 1
15 Pressure Gauge 1
16 Male Connector (3/8″) 4
L1-) W/(9-'4)'+= g)]
17 Water Trap 1
18 Air Valve (3/8″) 1
18A Throttle Valve (3/8″) 1
18B Abrasive Valve (3/8″) 1
19 Air Inlet 1
20 Male Connector 1
21 Air Hose 1
22 Abrasive Outlet Manifold 1
23 Hose Clamp 2
24 Abrasive Hose 1
29 Funnel 1
30 Safety Hood 1
30A Safety Hood Lens 1
50 Washer 4
51 Wheel Washer 4
L1-)(*V'()*1=>*W'18-1:
L1-)(*V'()*D*U<1()/-
M/9+->*L-+>,9)`(*G/-'1<*O,:0/-*Y/-/2*
O+)/2 If product has no serial number, record month and year of purchase instead.
O+)/2 Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175321381 when ordering parts.
L1-) W/(9-'4)'+= g)]
31 Upper Body 1
32 Lower Body 1
33 Metal Pipe 1
34 Intake Connector 1
35 Adapter 1
36 Gasket 1
37 Nozzle 4
38 Rubber Adapter 4
39 Nozzle Cap Nut 1
40 Screw (ST4.2x16) 4
L1-) W/(9-'4)'+= g)]
41 Screw (ST4.2x12) 2
42 Trigger Valve 1
43 Spring Pin 1
44 Spring 1
45 Rubber Pad 1
46 Screw (M3x25) 1
47 Hard Alloy Pad 1
48 Nut (M3) 1
49 Hose Adapter 1
L1-)(*V'()*D*U<1()/-*T,=
