CENTURION SYSTEMS D3 SMART - SMART Operator Theft-Deterrent Cage Installation; Important Safety Note on Magnet System; Installing the Theft-Deterrent Cage

page 6 www.centsys.com
4. SMART Operator Theft-Deterrent Cage Installation
SMART OPERATOR THEFT-DETERRENT CAGE INSTALLATIONSECTION 4
FIGURE 4
Overstrap
SMART
Operator
Place the Overstrap over the top of
the SMART Operator.
IMPORTANT!
In the case where one has the optional magnet origin system tted,
relocate the gate magnet as close as possible to the operator cover and
reset the gate limits.
FIGURE 3
SMART
Operator
Cover
Gearbox
Plug
Gearbox
Plug
Gearbox
Push the two Gearbox Plugs (one on
either side of the Gearbox) into the
Gearbox.
There is no need to remove
the cover of the SMART
Operator to install the
SMART Operator
Theft-Deterrent Cage.
Images may vary according to the SMART Operator.
