- 20 - INSTALLATION MANUAL – RDO
13.5. Learn Button
• The “Learn Button” (Figure. 17) is located within the Lamp Cover adjacent to the “Learn LED” and serves to
initiate the functions as described in Table 2:
Function
Action
Learn remote control code
Momentary press
Formal Force Learning
Press and hold for two seconds
Table 2
13.6. LED Display
• The LED Indicator (Figure.17) is located under the Courtesy Lamp Cover and serves visual indication of
functionality sequences as described in Table 3:
Display
Indicator
Glow Solid
Reached close limit position.
Slow Flash
Reached open limit position.
Medium Flash
Learning or deleting remote control codes
Quick Flash (A Mode)
Learning new drive force parameters
Quick Flash (M Mode)
Force adjust mode activated
Table 3
13.8. Run Button
• The black “Run” Button (Figure.17) is located under the Lamp cover and serves to initiate the functions as
described in Table 4:
Function
Action
Activate RDO II
Momentary press
Table 4
13.9. Safety Beams
• The CENTURION i5 or other four-wire Safety Beams may be connected to the RDO II (For two-wire beams, set
the jumper to 2W. For four-wire beams, set the jumper to 4W (Figure 19))
• The installation of Safety Beams greatly enhances safety by constantly monitoring for persons or objects which
may pass within the path of the moving garage door
• The RDO II will commence to Safety Reverse if the Safety Beams become momentarily or permanently
interrupted during a Close Cycle
Mounting
• Mark the inside garage door framing so that the bottom edge of the i5 beam sits 125mm off the floor
• Using a small angle bracket, fasten each beam to the wall so that they face each other across the garage door
Connection
• Follow Safety Beam instructions and connect to the Output Terminals. Use the normally-open contacts of the beam
to connect to input SB4 on the RDO (Figure 19A/B)
Important note: RDO II provides 24V DC output and normally-open input.
Alignment
• Adjust the Safety Beam module marked “Transmitter” (by turning the mounting bracket) so that it is aimed
directly at the lens of the Safety Beam module marked “Receiver”. A GREEN indicator lamp located on the
“Receiver” will glow once the correct alignment has been achieved
• Test the Safety Beam alignment several times, each time ensuring that when the Safety Beams are obstructed
the green indicator lamp extinguishes and when unobstructed the indicator lamp glows solid
• Firmly tighten the Safety Beam mounting bracket fixing screws
• Installation of the Safety Beams is now complete
Enabling
• Remove the Courtesy Lamp and Control Box Covers to expose the Control Board
• Select Dip 2 (SB) to the “ON” position (Figure.20)
• Replace the Control Box and Courtesy Lamp Cover
