Polophone Intercom - Page 7
WIRING
Fig 3 Cable Thickness Schedule
2 WIRES
0,2mm² 0,4mm²
0,4mm² 0,8mm²
2 WIRES
PSU
12V DC
PSU
14V DC
LOCATION OF
POWER SUPPLY
LOCATION OF
POWER SUPPLY
FROM
COMPONENT
TO
COMPONENT
NUMBER
OF WIRES
CABLE DISTANCE
<150M<100M
Door Lock DriveDoor Lock Drive
Fig 4 Door Lock Drive
Polophone Intercom - Page 7
WIRING
Fig 3 Cable Thickness Schedule
2 WIRES
0,2mm² 0,4mm²
0,4mm² 0,8mm²
2 WIRES
PSU
12V DC
PSU
14V DC
LOCATION OF
POWER SUPPLY
LOCATION OF
POWER SUPPLY
FROM
COMPONENT
TO
COMPONENT
NUMBER
OF WIRES
CABLE DISTANCE
<150M<100M
Door Lock DriveDoor Lock Drive
Fig 4 Door Lock Drive
DOOR LOCK
11
22
__
++
NONO
COMCOM
LOCK
POWER SUPPLY
ENTRY PANEL
NO
2
1
+
-
COM
If the gate trigger wire is connected to a potential free contact (NO or COM)
on the entry panel, the gate can be opened by joining the NO and COM
terminals together.
For additional security it is advisable to wire to the auxiliary terminals on
the handset or connect the PoloSwitch in the gate motor.
WARNING
