Revision: 02/1015 DOK 1643-us 11 of 28
Figure 8
a Earphone on the left side b Ear microphone on the right side
c Ear microphone with earphone d ASR microphone
5.3.2 Earphone with BoomMike
The earphone with boom microphone is available only for the left ear. Attached to the earphone is the
boom microphone with protective cover (Figure 9/c) and the ASR microphone (Figure 9/b).
Figure 9
b ASR microphone
c BoomMike with protective cover
