CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 25
13. A/D Controller Board Pin Description
CN7 LCD LVDS
PIN FUNCTION
1 PANEL VCC
2 PANEL VCC
3 PANEL VCC
4 OPTION
5 OPTION
6 OPTION
7 RXE1N3+
8 RXE1N3-
9 RXECKIN+
10 RXECKIN-
11 RXE1N2+
12 RXE1N2-
13 RXE1N1+
14 RXE1N1-
15 RXE1N0+
PIN FUNCTION
17 GROUND
18 GROUND
19 RXOCKIN-
20 GROUND
21 RXO1N3+
22 RXO1N3-
23 RXOCKIN+
24 RXOCKIN-
25 RXO1N2+
26 RXO1N2-
27 RXO1N1+
28 RXO1N1-
29 RXO1N0+
30 RXO1N0-
31 GROUND
16 RXE1N0- 32 GROUND
