CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 24

13. A/D Controller Board Pin Description

CN6 VIDEO ITU656, LIGHT SENSOR

PIN FUNCTION

1 DATA0

6 DATA5

4 DATA3

3 DATA2

2 DATA1

5 DATA4

9 GROUND

8 DATA7

7 DATA6

10 GROUND

CN8 INVERTER

PIN FUNCTION

1 +5/+12/+24

2 +5/+12/+24

3 +5/+12/+24

4 ADJUST

5 ON/OFF

6 GROUND

7 GROUND
