CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 23

13. A/D Controller Board Pin Description

CN2 24VDC INPUT

PIN FUNCTION

1 +24 VDC

6 GROUND

4 GROUND

3 +24 VDC

2 +24 VDC

5 GROUND

CN3 TOUCH POWER

PIN FUNCTION

1 +12VDC

2 +5VDC

3 GROUND

CN5 GPIO, UART

PIN FUNCTION

1 +5VDC

2 GROUND

3 DI

4 DO

5 GPIO

6 GPIO
