13MB Pool & spa heater
13
2-06-04
A
*Electrical Connection On Left Side is 486mm (19
-1/8")
(38")
Gas Connection (13-1/4")
(9¾")
(4
-3/8")
111mm
247mm
1015mm
675mm (26-1/2")
(*21-1/4")
*540mm
(26 ½")
673mm
965mm
336mm
(C)
INDOOR DRAUGHT
HOOD
185 1590 mm (62
5/8
")
265 1597mm (62
7/8
")
405 1570mm (61¾")
SPECIFICATIONS & DIMENSIONS 185 - 265 - 405
MODEL WIDTH FLUE DIA CONNECTIONS SHIPPING WEIGHT
(A) (B) GAS WATER kg (lbs)
mm (in.) mm (in.) APPLIANCE DIVERTER
185 464 (18 1/4) 150 (6) ¾" 2" NPT 86.8 (191) 5.5 (12)
265 568 (22 3/8) 175 (7) ¾" 2" PLASTIC 97 (214) 7 (15)
405 743 (29 1/4) 230 (9) ¾" 2" PLASTIC 115 (253) 9 (20)
DIMENSIONS - 155 Model Only
610mm
(24")
1140mm
(44 -
7/8")
770mm
(30 -
3/8")
390mm
(15 -
3/8")
370mm
(14 -
1/2")
680mm
(26 -
3/4")
900mm
(35 -
1/2")
220mm
(8 -
3/4")
85mm
(3 -
3/8")
Gas Con-
nection
(B)
(40")
