TM70Bi.v1.1.doc (10/03) 9
DATA: When ON indicates that the data received has a correct format.
ID: When ON indicates that the receiver has recognised the transmitter’s
identification code..
Now, the STOP relays K15 and K16 relays will be activated. The K2/START relay is
activated once the start button is pushed.
Press on any of the transmitter’s movement buttons and its corresponding relay will be
activated. In case of an active movement, the safety relay K1/SAFETY will also
activate.
Check to make sure all the other movements work in this way.
Turn off the transmitter using the STOP button, and make sure that when doing so the
relays are deactivated and the DATA, ID and SIGNAL LED’s go out. They should
behave exactly as in the ‘SCANNING’ mode.
Reconnect the power supply to the motors, move to a safe position and check to see if
all the movement buttons and the stop button are functioning correctly.
